Category summary of the current mainstream jaw crusher models and key parameters, covering environmentally friendly, fine crushing, large coarse crushing equipment and other categories.
Environmentally friendly jaw crusher
JSA125×100 series
Feed size: 125×100mm
Processing capacity: 300-2000kg/h
Motor power: 3kW
Features: double flywheel design, high manganese steel jaw plate, one-button start device, suitable for medium hardness ore crushing.
JSXJ100×60 fine crusher
Discharge size: <1mm (100%)
Processing capacity: 50-200kg/h
Jaw plate material: chrome steel, specially used for laboratory fine crushing
Large Coarse Crushing Equipment
1300×1600 (1316 jaw crusher)
Hourly output: 850-1220t/h
Motor power: 239kW
Applicable materials: granite and other high-hardness ores, suitable for annual production of 3 million tons
PE600×900
Processing capacity: 50-160t/h (depending on the material Floating)
Motor power: 55kW
Structural features: deep "V" shaped crushing chamber, low noise design, suitable for medium-sized stone processing plants
Fine Crushing And European Version Models
PEX series fine jaw crusher
Representative model: PEX-250×1000
Processing capacity: 8-105t/h
Discharge opening adjustment range: 18-90mm, suitable for secondary fine crushing
CJ European version jaw crusher
Model example: CJ150
Processing capacity: 240-950t/h
Features: Non-welded detachable structure, suitable for coarse crushing of high hardness materials
